Seta Multiflash Cleveland Flash Point Module
The automatic Cleveland module conforms precisely to national and international Cleveland open cup flash point test methods. It comprises a sample cup, temperature probe, flash/fire detector, and a DIPS pod containing the sweeping mechanism with co-axial gas/electric ignitor.
The Cleveland module must be used with the Multiflash Automatic Flash Point – Universal Base Unit (34000-0). The base unit recognises that the Cleveland module is connected and instantaneously sets up standard test parameters and calibration data.
Seta Multiflash Cleveland Flash Point Module
Features
- Fully self-contained flash/fire point test module
- Ambient to 400 °C
- Gas or electric ignition
- Automatic heating control, flash and fire detection
- Automatic test results & end of test audible warning
- Automatic snuffer
- Automatic barometric correction
Specifications
| Temperature Range | Ambient to 400 °C |
| Bath | N/A |
| Heating | Hotplate |
| Post Test Cooling | Fan assisted or Forced Air (Requires 34008-0 Cooling Boost Module option) |
| Post Test Cool-Down Time (90°C TO 50°C) | 9 minutes (Fan) 6 minutes (Forced Air) |
| Ignitor | Quick-fit coaxial gas jet / electric hot wire, user selectable (Electric hot wire pilot light for gas jet) |
| Temperature Probe | 30 rpm |
| Gas Supply (Gas Jet Ignitor) | Class A Platinum Resistance Thermometer, °C or °F |
| Flash/ Fire Detection | Ionisation Ring |
| Gas Supply (Gas Jet Ignitor) | Laboratory gas, 3 kPa (0.44 psi) maximum pressure |
| Air Supply (Forced Air Cooling) | Dry compressed air, 670 kPa (100 psi) maximum pressure |
| Voltage | 110/120 V or 220/240 V, 50/60 Hz, (switchable) |
| Power | 1 kW |
| Size (HXWXD) | 330 x 470 x 420 mm |
| Weight | 12 kg |
