AFIDA – Indicated Cetane Number Analyser – SA6000-0

AFIDA is a revolutionary development providing you with a fully automated way of determining Indicated Cetane Number (ICN) of diesel and diesel related fuels. The AFIDA can analyse multiple samples in sequence and selects the samples using the 36-place autosampler. Only a small sample volume of 40 ml is required per test with a short analysis time of approximately 25 minutes.

The analyser uses a Constant Volume Combustion Chamber (CVCC) and incorporates a unique and patented high pressure injection system that generates fine fuel droplets similar to modern common rail injectors in most diesel engines.

An ultra robust temperature controlled piezo electric injector provides rapid switching and highly repeatable fuel metering, offering you improved performance and consistency when compared with solenoid controlled injectors and pintle type nozzles.

request a quote

Do NOT CHANGE OR REMOVE THIS ELEMENT

AFIDA – Indicated Cetane Number Analyser – SA6000-0

Spares and accessories

Features

Excellent correlation to ASTM D613, IP 41 and BS EN ISO 5165, BS 2000-41, ISO 5165
Wide sample types – middle distillates, blend components, biodiesel, FAME, XTL, HVO, heating oil and Jet A1
Suitable for use with Cetane improvers
Calibrated with industry approved PRFs over the range 35 to 85 ICN
Precise and reproducible software controlled determination of ICN
Results saved to PC or for download
Stable calibration – fixed test conditions eliminates routine temperature tuning
Low running costs, single gas supply for combustion air
Direct correlation to ASTM D613 (ISO 5165) engine tests
Multiple integral safety monitoring functions
Standardisation

Specifications

Chamber Temperature	580 °C
Chamber Pressure	17.5 bar
Injection Pressure	1000 bar
Compressed Air	20.9 ± 0.5 % O2
Sample Volume	approx. 40 ml for analysis and cleaning
Warm Up Time	approx. 45 min
Analysis Time	approx. 25 min per sample
Size (DXHXW)	1300 mm x 800 mm x 600 mm (excluding platform)
Weight	160 kg 100 kg (excluding platform)
CCCN Code	Tariff 90318080

Manufacturers

show DATA — DO NOT CHANGE ID–

Document

AFIDA SA6000-0 Brochure

Industries

show DATA — DO NOT CHANGE ID–

Methods

show DATA — DO NOT CHANGE ID–

Spares and accessories for Cetane Number Analyser

Pressure Regulator Panel AFIDA – SA6005-0

Pressure regulator panel to connect and regulate the air supply to the AFIDA (SA6000-0). Includes a wall mounted regulator, filter and pressure gauge.

AFIDA Start Up Kit – SA6003-0

Start up kit to perform 100 AFIDA (SA6000-0) tests. Supplied with 1 x PRF calibration set, 1 x ambered vials (pack of 100), 1 x septums (pack of 100), 1 x caps (pack of 100), 1 x syringe filters (pack of 100), 1 x 500 ml cleaning fluid, 1 x 5 litre antifreeze coolant, 1 x pump valve service kit, 1 x verification fluid, 1 x torque wrench tool kit, 1 x 20 ml syringes (pack of 100)

Show More Show Less

Cleaning Fluid – SA6003-006

500 ml bottle of 1-decanol cleaning fluid for use with the AFIDA (SA6000-0).

AFIDA Syringes (pack of 80) – SA6003-005

Pack of 80 x 20 ml syringes for use with the AFIDA (SA6000-0).

AFIDA Syringe Filters (pack of 100) – SA6003-004

Pack of 100 syringe filters for use with the AFIDA (SA6000-0).

AFIDA Caps (pack of 100) – SA6003-003

Pack of 100 caps for use with the AFIDA (SA6000-0).

AFIDA Septums for Sample Vials (pack of 100) – SA6003-002

Pack of 100 septums for use with the ambered sample vials for the AFIDA SA6000-0.

AFIDA Ambered Vials (pack of 100) – SA6003-001

Pack of 100 ambered vials for use with the AFIDA (SA6000-0).

AFIDA PRF Calibration Set – SA6002-0

A set of calibration fluids for use with the AFIDA (SA6000-0). The set includes seven glass vials that cover calibration points of Indicated Cetane Number (ICN) 35, 40, 46, 53, 60, 70 and 85. The vials consist of volumetric blends of primary reference fuels n-hexadecane and 1-methylnapthalene.
