SetaCheck Biodiesel – SA5500-0
SetaCheck Biodiesel is a handheld instrument designed to provide fast, accurate and repeatable on-site measurement of biodiesel content in diesel fuel blends.
Using unique, Mid-IR technology, the analyser has a measurement range of 0.1% to 40% biodiesel. Only 2 ml of sample is required and a test is completed in less than 1 minute with results displayed on a bright backlit screen.
SetaCheck’s test procedure is simple, requiring no special technical skills or laboratory conditions, making it ideal for batch checking fuels at terminals to monitoring standby fuel supplies.
SetaCheck Biodiesel – SA5500-0
Features
- 0.1% to 40% measurement range
- Internal rechargeable battery
- No dilution required, samples measured directly
- Correlates with EN 14078
- User calibration available via PC software
specifications
| RANGE | 0.1% to 40% |
|---|---|
| OPERATING TEMPERATURE | 5 – 40 °C |
| TEST DURATION | Less than 1 minute |
| MEASURING UNITS | % by volume |
| SAMPLE VOLUME | Approx 2 ml |
| NUMBER OF TESTS | In excess of a hundred tests on a single charge |
| CHARGING | Micro USB |
| POWER | Rechargeable lithium ion battery |
| SIZE (HXWXD) | 36 x 150 x 200 mm |
| WEIGHT | 1 kg |
| CCCN CODE | Tariff Code 90268020 |
Manufacturers
show DATA — DO NOT CHANGE ID–
Document
SetaCheck Biodiesel – SA5500-0
Industries
show DATA — DO NOT CHANGE ID–
Methods
show DATA — DO NOT CHANGE ID–
Spares and accessories for SA5500-0
Inlet Tube Assembly (Pack of 3) – SA5500-001
For use with the SetaCheck Biodiesel (SA5500-0).
Beaker 50 ml (pack of 10) – SA5004-010
Pack of 10 x 50 ml beakers for use with the FIJI JF – FAME in Jet Instrument (SA5000-2), FIJI DRG – FAME in Distillate & Residual Fuels (SA5100-0), FIJI MF – FAME in MultiFuels (SA5200-0) and SetaCheck Biodiesel (SA5500-0).
SetaCheck Verification Kit – SA5502-0
For use with the SetaCheck Biodiesel (SA5500-0) for performance verification.
SetaCheck Calibration Kit – SA5501-0
For use with the SetaCheck Biodiesel (SA5500-0).
