Seta Multiflash Cleveland Flash Point Module – 34300-2

The automatic Cleveland module conforms precisely to national and international Cleveland open cup flash point test methods. It comprises a sample cup, temperature probe, flash/fire detector, and a DIPS pod containing the sweeping mechanism with co-axial gas/electric ignitor.

The Cleveland module must be used with the Multiflash Automatic Flash Point – Universal Base Unit (34000-0). The base unit recognises that the Cleveland module is connected and instantaneously sets up standard test parameters and calibration data.

request a quote

Do NOT CHANGE OR REMOVE THIS ELEMENT

Seta Multiflash Cleveland Flash Point Module – 34300-2

Spares and accessories

Features

Fully self-contained flash/fire point test module
Ambient to 400 °C
Gas or electric ignition
Automatic heating control, flash and fire detection
Automatic test results & end of test audible warning
Automatic snuffer
Automatic barometric correction

specifications

TEMPERATURE RANGE	Ambient to 400 °C
BATH	N/A
HEATING	Hotplate
POST TEST COOLING	Fan assisted or Forced Air (Requires 34008-0 Cooling Boost Module option)
POST TEST COOL-DOWN TIME (90°C TO 50°C)	9 minutes (Fan) 6 minutes (Forced Air)
IGNITOR	Quick-fit coaxial gas jet / electric hot wire, user selectable (Electric hot wire pilot light for gas jet)
TEMPERATURE PROBE	30 rpm
GAS SUPPLY (GAS JET IGNITOR)	Class A Platinum Resistance Thermometer, °C or °F
FLASH / FIRE DETECTION	Ionisation Ring
GAS SUPPLY (GAS JET IGNITOR)	Laboratory gas, 3 kPa (0.44 psi) maximum pressure
AIR SUPPLY (FORCED AIR COOLING	Dry compressed air, 670 kPa (100 psi) maximum pressure
VOLTAGE	110/120 V or 220/240 V, 50/60 Hz, (switchable)
POWER	1 kW
SIZE (HXWXD)	330 x 470 x 420 mm
WEIGHT	12 kg
CCCN CODE	Tariff 90268020

Manufacturers

show DATA — DO NOT CHANGE ID–

Document

Seta Multiflash Cleveland Flash Point Module – 34300-2

Industries

show DATA — DO NOT CHANGE ID–

Methods

show DATA — DO NOT CHANGE ID–

Spares and accessories for 34300-2

Co-axial Ignitor (Multiflash PMCC, Cleveland) – 34100-004

Co-axial ignitor for use with the Multiflash Pensky-Martens Flash Point Module (34100-2) and the Multiflash Cleveland Flash Point Module (34300-2).

Insulating Collets (pack of 2) – 34300-014

Insulating cable for use with the Cleveland Multiflash Flash Point Module (34300-2).

Ionisation Ring (Multiflash Cleveland) – 34300-201

Ionisation ring for use with the Multiflash Cleveland Flash Point Module (34300-2).

Dry Well Probe Calibrator – 60005-002

A portable instrument designed to provide quick and accurate calibration of thermocouple and RTD temperature probes.

Cleveland Standard 80 ml (3 pack) – 99882-0

Designed specifically for use in determining flash points in petroleum products by the Cleveland Open Cup method.

FLASHCHECK (pack of 3 x 80 ml) – 99880-0

FLASHCHECK is a highly cost effective & non-hazardous Secondary Working Standard suitable for verification of ASTM, CEN, ISO, IP and equivalent flash point testing procedures.
